Description
Intel Core i9-14900K, Intel® Core™ i9, LGA 1700, Intel, i9-14900K, 64-bit, Intel Core i9-14xxx
| Processor | |
| Processor family | Intel® Core™ i9 |
| Number of processor cores | 24 |
| Processor socket (processor receptacle) | LGA 1700 |
| Box | Yes |
| Cooler included | No |
| Processor manufacturer | Intel |
| Processor model | i9-14900K |
| Processor operating modes | 64-bit |
| Generation of processors | Intel Core i9-14xxx |
| Number of CPU threads | 32 |
| Performance Cores | 8 |
| Effective hearts | 16 |
| Turbo processor frequency | 6GHz |
| Supercharging frequency of high-performance hearts | 5.6GHz |
| Base frequency of high-performance hearts | 3.2GHz |
| Supercharging frequency of efficient hearts | 4.4GHz |
| Base frequency of effective hearts | 2.4GHz |
| CPU cache | 36 MB |
| Processor Cache Type | Smart Cache |
| Core CPU Power | 125W |
| Maximum turbo power | 253W |
| Stepping | B0 |
| Maximum number of DMI channels | 8 |
| Memory bandwidth supported by processor (max) | 89.6 GB/s |
| Processor code name | Raptor Lake |
| Processor ARK ID | 236773 |
| Memory | |
| Memory Channels | Dual channel |
| Maximum internal memory supported by the processor | 192 GB |
| Memory types supported by the processor | DDR4-SDRAM, DDR5-SDRAM |
| ECC | Yes |
| Non-ECC | Yes |
| Memory bandwidth (max) | 89.6 GB/s |
| Chart | |
| Integrated graphics card | Yes |
| Separate graphics card adapter | No |
| Graphics adapter model included | Intel UHD Graphics 770 |
| Separate graphics adapter model | Unavailable |
| Supported graphics card outputs | Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1 |
| Integrated graphics card base frequency | 300 MHz |
| Dynamic frequency (max) of integrated graphics card | 1650 MHz |
| Number of displays supported by the integrated graphics card | 4 |
| DirectX version of integrated graphics card | 12.0 |
| OpenGL version of integrated graphics card | 4.5 |
| Maximum resolution (DisplayPort) of the integrated graphics card | 7680 x 4320 pixels |
| Maximum resolution (eDP - Integrated Flat Panel) | 5120 x 3200 pixels |
| Maximum resolution (HDMI) of integrated graphics card | 4096 x 2160 pixels |
| Refresh rate at maximum resolution (DisplayPort) | 60Hz |
| Refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 120Hz |
| Refresh rate at maximum resolution (HDMI) | 60Hz |
| Integrated graphics card ID | 0xA780 |
| Number of execution units | 32 |
| Multi-format codec engines | 2 |
| Features | |
| Lock bit | Yes |
| Idle States | Yes |
| Thermal monitoring technologies | Yes |
| Market segment | Desk |
| Terms of use | Workstation, PC/Client/Tablet |
| Maximum number of PCI Express lanes | 20 |
| PCI Express slot version | 4.0, 5.0 |
| PCI Express configurations | 1x16+1x4, 2x8+1x4 |
| Supported instruction set | AVX 2.0, SSE4.1, SSE4.2 |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Built-in options available | No |
| Thermal solution specification | PCG 2020A |
| Revision of the DMI (Direct Media Interface) | 4.0 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
| Special processor features | |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Quick Sync Video Technology | Yes |
| Intel Clear Video Technology HD | Yes |
| New Intel® AES Instructions (Intel® AES-NI) | Yes |
| Intel Advanced SpeedStep Technology | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® Thermal Velocity Boost | Yes |
| Intel® Adaptive Boost Technology | Yes |
| Intel® Turbo Boost Max Technology 3.0 frequency | 5.8GHz |
| Intel® Gaussian and Neural Accelerator (Intel® GNA) 3.0 | Yes |
| Intel® Thermal Velocity Boost Frequency | 6GHz |
| Intel® Control-flow Enforcement Technology (CET) | Yes |
| Intel® Thread Director | Yes |
| Intel® VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Security Key | Yes |
| Intel® Guard SE | Yes |
| Intel® 64 | Yes |
| Intel® Vitalization Technology (VT-x) | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Turbo Boost Max Technology 3.0 | Yes |
| Intel® Boot Guard | Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® Standard Management (ISM) | Yes |
| Environmental conditions | |
| Tjunction | 100°C |
| Technical details | |
| OpenCL version | 3.0 |
| Release date | Q4'23 |
| State | Launched |
| Logistics data | |
| Harmonized System Code | 8542310001 |
| Weight and dimensions | |
| Processor Package Size | 45 x 37.5mm |
| Other features | |
| L2 cache | 32768 KB |
| Maximum internal memory | 192 GB |
| Graphics output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
