External USB 3.0 Video Adapter | 4x 1080p | Quad DisplaysThis USB 3.0 to HDMI© adapter lets you expand your desktop by adding four independent HDMI displays or monitors to your laptop or desktop using a single USB Type-A port. Maximize your productivityThis USB adapter- A to 4 HDMI ports has four video outputs to boost your productivity by increasing your screen work space. By working on multiple screens, you have the freedom to access multiple applications at the same time and view information on one screen while working on the other. Use the USB to HDMI Multi-Display Adapter to extend or duplicate your displays, or create an eye-catching video wall.High-definition audio and videoTaking advantage of the USB 3.0 interface, this quad-display adapter dongle delivers maximum high-definition resolutions of 1920 x 1080 (1080p) on all four ports. The adapter also supports 2-channel audio in HDMI.Easy InstallationThe USB Type-A to HDMI display adapter converter is equipped with an included 1m USB-A cable, which increases the distance between the adapter and your host device, for flexible configuration. It also supports automatic driver installation, ensuring ease of use. The external video adapter is bus-powered, without requiring an external power supply. Multi-Monitor Assistant software The Multi-Monitor Assistant application provides multitasking user interface, allowing you to quickly switch between screens. This app offers additional features, helping users perform various tasks, such as dragging and dropping items, zooming, split scaling, and cascading windows to the main screen, as well as such as creating a matrix wall or dynamic video wall. Note: All four displays must be the same size and resolution to create a video wall. The adapter can only duplicate two additional displays .The StarTech.com Advantage
| representation / production |
| USB version |
3.2 Gen 1 (3.1 Gen 1) |
| DVI output |
No |
| HDMI output |
Yes |
| DisplayPorts output |
No |
| Number of supported displays |
4 |
| USB connector |
USB Type-A |
| USB connector type |
Male |
| USB connector form factor |
Right |
| Quantity of HDMI ports |
4 |
| Maximum resolution |
1920 x 1080 pixels |
| Refresh rate at maximum resolution |
60Hz |
| Component set |
Trigger T6-688SL, IT66121 |
| Design
|
| Product color |
Gray |
| Housing/Body Material |
Aluminum |
| Integrated USB cable |
Yes |
| USB cable length |
1m |
| Minimum system requirements
|
| Windows operating system support |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64 |
| Environmental conditions
|
| Operating temperature |
0 - 45°C |
| Non-operating temperature |
-10 - 75°C |
| Relative operating humidity (HH) |
0 - 85% |
| Weight and dimensions
|
| Width |
80mm |
| Depth |
101mm |
| Height |
16mm |
| Weight |
180g |
| Package width |
207mm |
| Package depth |
144mm |
| Package height |
38mm |
| Package weight |
280g |
| Package Contents
|
| Quick Installation Guide |
Yes |
| Technical details
|
| Sustainability certificates |
CE, RoHS |
| Logistics data
|
| Produced by main (external) locker |
40 piece(s) |
| Width of main locker (external) |
445mm |
| Length of main locker (external) |
310mm |
| Height of main (external) locker |
430mm |
| Harmonized System Code |
84733020 |
