VESA Certified DisplayPort 1.4 Cable - 8K 60Hz HDR10 - 5mThis DisplayPort 1.4 cable connects your DisplayPort™ laptop or desktop to an 8K ultra-high definition display, TV or projector. It supports resolutions up to 8K (7680 x 4320) at 60 Hz.The DisplayPort monitor cable provides the essential connection to support the next generation of ultra-high definition video.This VESA© certified cable ensures full compliance and efficient operation of the highest link rate of HBR3. It has been tested to meet all DP 1.4 specifications to ensure quality and reliability.Superior DisplayPort 1.4 PerformanceThis 8K DisplayPort cable supports all DP 1.4 features:• High Bit Rate 3 (HBR3) bandwidths of 32.4 Gbps supporting the latest industry standards• High Dynamic Range (HDR10) for higher contrast ratio and vivid colors• Multi-Stream Transport (MST) for daisy-chaining multiple monitors• Display Stream Compression 1.2 (DSC) for maximum resolution output• Upstream Error Correction to handle data transmission errors• High-Bandwidth Digital Content Protection (HDCP 2.2) for a secure connection between source and display• 32 channels of uncompressed digital audioCable Key FeaturesAluminum-mylar foil with braided shielding enhances protection against electromagnetic interference.[HTMLLINEBREAK]Long-lasting flexible TPE jacket and discharge tensile (TPE is non-toxic and halogen-free for environmental sustainability)Key Connector FeaturesDie-cast aluminum substructure shielding improves signal integrity and prevents signal degradation[HTMLLINEBREAK]Corrosion-free gold-plated connectors ensure superior video quality and greater reliability. Tested to withstand over 5000 insertions8K: For Business Continuity8K's 7680 x 4320 resolution is also known as 4320p and Ultra High Definition (UHD). It is suitable for digital signage and other commercial displays that require the highest resolution available. This cable is backwards compatible with 4K and 5K displays, making it the perfect device to start future-proofing your cabling infrastructure. Extensive Product Testing and Expert Technical SupportStarTech.com conducts extensive compatibility and performance testing on all of its products to ensure we meet or exceed industry standards and deliver high-quality products to our customers. Our local StarTech.com Technical Advisors have extensive product expertise and work directly with StarTech.com engineers to provide support to our customers both before and after the sale.DP14VMMV5M is backed by a StarTech.com Lifetime Warranty.The StarTech.com Advantage
| Features |
| Cable length |
5 m |
| Connector 1 |
DisplayPort |
| Connector 2 |
DisplayPort |
| Connector type 1 |
Male |
| Connector type 2 |
Male |
| Maximum resolution |
7680 x 4320 pixels |
| Product color |
Grey, Black |
| Connector form factor 1 |
Right |
| Connector form factor 2 |
Right |
| Plating connector contacts |
Gold |
| DisplayPort version |
1.4 |
| Supported Graphics Resolutions |
3840 x 2160, 7680 x 4320 |
| Maximum discount rate |
120 Hz |
| HDCP |
Yes |
| Locking connectors |
Yes |
| Cable shielding |
Mylar aluminum plate |
| Coat material |
Thermoplastic elastomer (TPE) |
| AWG Wire Size |
28 |
| HDR support |
Yes |
| Bandwidth |
32400 MB/s |
| HBR3 support |
Yes |
| Number of drivers |
19 |
| Environmental conditions
|
| Operating temperature |
0 - 50 °C |
| Non-operating temperature |
0 - 50 °C |
| Operating relative humidity (HH) |
0 - 85% |
| Sustainability
|
| Sustainability certificates |
RoHS |
| Packaging information
|
| Cable diameter |
7.5 mm |
| Weight |
372 g |
| Quantity |
1 piece(s) |
| Package width |
250 mm |
| Package depth |
330 mm |
| Package height |
26 mm |
| Package weight |
405 g |
| Logistics data
|
| Harmonized System Code |
84733080 |
| Main locker width (external) |
340 mm |
| Main locker length (external) |
400 mm |
| Height of main locker (external) |
290 mm |
| Produced by main (external) locker |
20 piece(s) |
