Description
Control 2 high-resolution dual DisplayPort computers with a single console
The SV231DPDDUA 2-Port Dual DisplayPort USB KVM Switch with Audio and USB 2.0 Hub combines the latest generation of digital signage standards with seamless KVM control, allowing you to switch between 2 dual DisplayPort systems. It's also ideal for systems offering a single DisplayPort output and a second video source such as DVI or HDMI with a low-cost adapter.
Allowing control of multiple computers for high-resolution multimedia applications, the KVM switch supports resolutions of 2560x1600 (at 60 Hz) with HD DisplayPort audio, as well as 2-way analog stereo audio input and microphone input.
Suitable for high-quality static imaging applications, such as medical applications (MRI, X-ray, etc.), it supports a maximum resolution of 3840x2400 at a reduced refresh rate.
Backed by StarTech.com's 3-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Versatile audio support via multi-channel DisplayPort HD digital audio or 3.5mm stereo analog audio
- Built-in USB 2.0 hub allows peripheral sharing to avoid having to purchase multiple duplicate devices (printers, scanners, etc.)
- This versatile KVM solution is compatible with Mini-DisplayPort, DisplayPort to DVI or HDMI adapters. It is ideal for Dual DisplayPort or DisplayPort + DVI or HDMI video outputs, and allows Macbook connectivity
The SV231DPDDUA 2-Port Dual DisplayPort USB KVM Switch with Audio and USB 2.0 Hub combines the latest generation of digital signage standards with seamless KVM control, allowing you to switch between 2 dual DisplayPort systems. It's also ideal for systems offering a single DisplayPort output and a second video source such as DVI or HDMI with a low-cost adapter.
Allowing control of multiple computers for high-resolution multimedia applications, the KVM switch supports resolutions of 2560x1600 (at 60 Hz) with HD DisplayPort audio, as well as 2-way analog stereo audio input and microphone input.
Suitable for high-quality static imaging applications, such as medical applications (MRI, X-ray, etc.), it supports a maximum resolution of 3840x2400 at a reduced refresh rate.
Backed by StarTech.com's 3-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Versatile audio support via multi-channel DisplayPort HD digital audio or 3.5mm stereo analog audio
- Built-in USB 2.0 hub allows peripheral sharing to avoid having to purchase multiple duplicate devices (printers, scanners, etc.)
- This versatile KVM solution is compatible with Mini-DisplayPort, DisplayPort to DVI or HDMI adapters. It is ideal for Dual DisplayPort or DisplayPort + DVI or HDMI video outputs, and allows Macbook connectivity
| Connectivity | |
| Number of computers monitored | 2 |
| Keyboard port | USB |
| Mouse port | USB |
| Video port | DisplayPort |
| Console ports | 3.5mm headset, 3.5mm mic, DisplayPort, USB A |
| DisplayPorts interface quantity | 6 |
| Quantity of console USB ports | 2 |
| USB hub | Yes |
| USB connector | USB Type-A |
| Audio Connections | Yes |
| Headphone output | 3 |
| Number of microphone inputs | 3 |
| DC input | Yes |
| Network | |
| Ethernet/LAN | No |
| representation / production | |
| HD type | 4K Ultra HD |
| Maximum resolution | 3840 x 2400 pixels |
| DDC2B support | Yes |
| Hot-Plug support | Yes |
| Daisy chaining | No |
| Number of users | 1 user(s) |
| Audio channels | 7.1 |
| Design | |
| Mounting grid | No |
| Product color | Black |
| Housing/Body Material | Steel |
| LEDs | Yes |
| Button push | Yes |
| Direct keys | Yes |
| Certification | CE, FCC, REACH, TAA |
| Screen | |
| Integrated screen | No |
| On-Screen Display (OSD) | No |
| Power | |
| AC input voltage | 110 - 240 V |
| Input current | 0.8A |
| Output voltage | 12V |
| Output current | 1.5A |
| Typical power consumption | 18W |
| External power adapter | Yes |
| Plug type | Type M |
| Compatible power plug types | AU, EU, UK, US |
| Sustainability | |
| Sustainability certificates | RoHS |
| Environmental conditions | |
| Operating temperature | 0 - 40°C |
| Non-operating temperature | 20 - 60°C |
| Relative operating humidity (HH) | 0 - 80% |
| Weight and dimensions | |
| Width | 161mm |
| Depth | 100mm |
| Height | 57.5mm |
| Weight | 734g |
| Packaging information | |
| Package width | 249mm |
| Package depth | 187mm |
| Package height | 100mm |
| Package weight | 1.19 kg |
| Package Contents | |
| User Manual | Yes |
| Logistics data | |
| Harmonized System Code | 85176200 |
| Other features | |
| Audio support | Yes |
| IP control | No |
