Description
1Gbps | Single mode | LC | 10km | Lifetime warranty
The 10056H-ST is an Extreme Networks 10056H compatible downstream fiber optic SFP transceiver that works with StarTech.com's 10056-ST. They are designed, programmed and tested to work with switches and routers compatible with MSA 1000Base-BX standards. The SFP+ transceiver module works up to a distance of 10 km and provides you with 1 GbE connectivity via optical cabling.
Technical specifications :
Wavelength: 1490 nm Tx / 1310 nm Rx
Maximum data transfer speed: 1 Gbps
Type: single mode
Connection Type: LC Connector
Maximum transfer distance: 10 km
MTBF: 286,217,327 hours
Power consumption: <1.3W
Digital Diagnostics Monitoring (DDM): Yes
This fiber optic SFP+ module is hot-swappable, making upgrades and replacements easier by reducing network outages.
StarTech.com SFPs
StarTech.com SFPs
All StarTech.com SFP and SFP+ transceiver modules are backed by a lifetime warranty and free, multilingual, lifetime technical support. StarTech.com offers a wide range of direct attach SFP modules and SFP cables that give you the convenience and reliability you need to rely on your network.
The StarTech.com Advantage
- Ensures reliable 1GbE connections over 1000Base-BX compatible networks
- StarTech.com SFP modules are backed by a lifetime warranty
- Pair with the 10056-ST module
The 10056H-ST is an Extreme Networks 10056H compatible downstream fiber optic SFP transceiver that works with StarTech.com's 10056-ST. They are designed, programmed and tested to work with switches and routers compatible with MSA 1000Base-BX standards. The SFP+ transceiver module works up to a distance of 10 km and provides you with 1 GbE connectivity via optical cabling.
Technical specifications :
Wavelength: 1490 nm Tx / 1310 nm Rx
Maximum data transfer speed: 1 Gbps
Type: single mode
Connection Type: LC Connector
Maximum transfer distance: 10 km
MTBF: 286,217,327 hours
Power consumption: <1.3W
Digital Diagnostics Monitoring (DDM): Yes
This fiber optic SFP+ module is hot-swappable, making upgrades and replacements easier by reducing network outages.
StarTech.com SFPs
StarTech.com SFPs
All StarTech.com SFP and SFP+ transceiver modules are backed by a lifetime warranty and free, multilingual, lifetime technical support. StarTech.com offers a wide range of direct attach SFP modules and SFP cables that give you the convenience and reliability you need to rely on your network.
The StarTech.com Advantage
- Ensures reliable 1GbE connections over 1000Base-BX compatible networks
- StarTech.com SFP modules are backed by a lifetime warranty
- Pair with the 10056-ST module
| representation / production | |
| SFP transceiver type | Optical fiber |
| Maximum data transfer rate | 1250 Mbps |
| Interface Type | SFP |
| Single-module fiber (FMN) compatible | Yes |
| Multi-module fiber (FMM) compatible | No |
| Optical fiber connector | L.C. |
| SFP Transceiver Standard | B.X. |
| Maximum transfer distance | 10000m |
| Tx wavelength (max) | 1490nm |
| Rx wavelength (max) | 1310nm |
| Ethernet over fiber cabling technology | 1000BASE |
| Double-sided system | Complete |
| Digital Diagnostic Monitoring (DDM) | Yes |
| Features | |
| Product color | Money |
| Hot Swap | Yes |
| Mean time between failures | 286217327 h |
| Brand Compatibility | Extreme Networks |
| Compatible products | 10056H |
| Certification | CE, FCC, UR, REACH |
| Power | |
| Typical power consumption | 1.3W |
| Weight and dimensions | |
| Width | 56.6mm |
| Depth | 13.7mm |
| Height | 12.5mm |
| Weight | 20g |
| Packaging information | |
| Number of products included | 1 piece(s) |
| Package width | 90mm |
| Package depth | 115mm |
| Package height | 31mm |
| Package weight | 50g |
| Technical details | |
| Sustainability certificates | RoHS |
| Logistics data | |
| Width of main locker (external) | 90mm |
| Length of main locker (external) | 115mm |
| Harmonized System Code | 85369010 |
| Height of main (external) locker | 31mm |
| Produced by main (external) locker | 1 piece(s) |
